24’3” x 46′ Sqft (2D+3D)

Description

2085 sqft – 2BHK

 GROUND FLOOR – DETAILED DESCRIPTION

 Portico – 8’5″ × 7’0″

• Located at the front side
• Accommodates:
  • 1 small car or 2 two-wheelers
• Covered slab provides:
  • Weather protection
  • Clear entry demarcation
• Can be finished with:
  • Anti-skid tiles
  • False ceiling with LED lights

 Waiting Area – 8’0″ × 10’0″

• Positioned immediately after the entrance
• Acts as buffer space between public and private zones
• Suitable for:
  • 4–6 chairs
  • Reception counter (optional)
• Ideal for:
  • Clinic
  • Consultancy
  • Small office setup

 Office Room – 10’0″ × 10’0″

• Directly connected to waiting area
• Square proportion → flexible furniture layout
• Can accommodate:
  • Office desk
  • Visitor seating
  • Storage cabinet
• Good ventilation possible via front/side window

 Hall (Living Area) – 8’3″ × 16’0″

• Long rectangular living space
• Functions:
  • Family seating
  • TV unit
• Can be divided visually into:
  • Seating zone
  • Circulation zone
• Suitable for:
  • Sofa set (3+1+1)
  • TV unit on long wall

Kitchen – 8’3″ × 10’0″

• Located near hall for easy access
• Supports:
  • L-shaped or parallel kitchen
• Adequate space for:
  • Cooking counter
  • Refrigerator
  • Overhead cabinets
• Window provision ensures:
  • Cross ventilation
  • Smoke exhaust

 Store Room – 5’0″ × 4’7.5″

• Attached to kitchen
• Used for:
  • Grocery storage
  • Kitchen equipment
• Can also house:
  • Inverter / UPS

 Common Toilet – 4’9″ × 5’0″

• Accessible from hall
• Compact but functional
• Suitable for:
  • Indian or Western WC
• Shared plumbing wall with attached toilet improves cost efficiency

 Master Bedroom – 10’1.5″ × 16’0″

• Spacious rectangular bedroom
• Can fit:
  • King-size bed
  • Wardrobe
  • Dressing table
• Enough clearance for comfortable movement

Attached Toilet (Master Bedroom) – 5’0″ × 5’0″

• Direct bedroom access
• Suitable for:
  • Shower
  • WC
  • Small wash basin
• Easy plumbing maintenance due to compact size

 Outside Staircase Area – 10’0″ × 7’0″

• Completely independent access
• Advantage:
  • Ground & first floors can function separately
  • Perfect for rental / office use
• Stair width allows comfortable movement
• Can be covered partially for weather protection

 FIRST FLOOR – DETAILED DESCRIPTION

✔ Same layout as ground floor (structural & cost advantage)

Differences from Ground Floor:

• Balcony (8’5″ × 7’0″) instead of portico
• Balcony usable as:
  • Sit-out
  • Utility drying space
• Provides:
  • Better elevation aesthetics
  • Additional ventilation

Usage Options:

• Full residential unit
• Office + residence
• Independent rental portion

 SECOND FLOOR – TERRACE LEVEL

 Head Room – 12’10” × 6’3″

• Covers staircase top
• Used for:
  • Stair access
  • Storage
  • Electrical panels
• Can be extended later into a room

 Open Terrace – 22’9″ × 37’6″

• Large usable open space
• Can be used for:
  • Family functions
  • Terrace garden
  • Sit-out with pergola
  • Solar panels
  • Future room construction
• Proper slope required for rainwater drainage
